Introduction of Rod Mill:
Rod mill is one of the sand making machine which is widely used in sand making industry. It is mainly used for processing and crushing of feldspar, quartz an d ore, etc. The mill body rotates as a certain speed. The grinding body is thrown down after be up to a certain height under the effect of friction and centrifugal force, so the materiel is impacted and achieves the aim of sand making.
Main technical parameters of Rod Mill:
Model | Mill body size(mm) | Rotating speed (r/min) | Feeding rod weight (t) | Feeding granularity (mm) | Discharging granularity (mm) | Output (t/h) | Motor power (kw) | Overall dimensions (mm) | Weight (kg) | |
Diameter | length | |||||||||
MB0918 | 900 | 1800 | 29.0-31.3 | 2.3 | <25 | 0.16-5 | 1.6-6 | 22 | 5900*2365*2015 | 4200 |
MB0924 | 900 | 2400 | 29.0-35.4 | 3.1 | <25 | 0.16-5 | 2.9-10 | 30 | 5250*2480*2127 | 5300 |
MB1224 | 1200 | 2400 | 27.0-34.0 | 6.5 | <25 | 0.16-5 | 5.0-13 | 37 | 5829*2867*2540 | 11800 |
MB1530 | 1500 | 3000 | 26.5-29.5 | 11.5 | <25 | 0.16-5 | 6.0-25 | 90 | 7635*3329*2749 | 18170 |
MB1830 | 1800 | 3000 | 21.6-22.8 | 17.5 | <25 | 0.16-5 | 4.8-28 | 155 | 8007*3873*3023 | 35000 |
MB2130 | 2100 | 3000 | 19.0-21.0 | 23.5 | <25 | 0.16-5 | 12.6-30 | 210 | 9000*2800*3800 | 43000 |
MB2136 | 2100 | 3600 | 19.0-21.0 | 23.2 | <25 | 0.16-5 | 15.1-45 | 245 | 9600*2800*3800 | 48000 |
MB2736 | 2700 | 3600 | 17.2-18.5 | 47.0 | <25 | 0.16-5 | 25.0-75 | 400 | 10870*6100*4950 | 71500 |
MB2740 | 2700 | 4000 | 17.2-18.5 | 51.0 | <25 | 0.16-5 | 27.7-90 | 430 | 11500*6100*4950 | 73600 |
