Concentrator introduction:
The high efficiency concentrator machine of our company is suitable for dehydrating water of the concentration and gangue in the concentrating factory which can make the mash of 20-30% raise up to 40-70% about. It is widely used for melting, chemical, coal, non metal concentration, environment protected etc industry.
Main techncial parameters of high efficiency concentrator:
Model | Driving method | Concentration pond | Capacity (t/24h) | Motor | Dimension (LxWxH) (mm) | ||
Diameter (mm) | Center depth (mm) | Model | Power (kw) | ||||
NZS-1 | Central | 1.8 | 1.8 | 5.6 | Y90L-6 | 1.1 | 2000x1960x2900 |
NZS-3 | Central | 3.6 | 1.8 | 22.4 | Y90L-6 | 1.1 | 3917x3787x3190 |
NZS-6 | Central | 6 | 3 | 62 | Y100L2-4- | 3 | 6170x6170x5053 |
NZS-9 | Central | 9 | 3 | 140 | Y132S-6 | 3 | 10000x10000x5337 |
NZS-12 | Central | 12 | 3.5 | 250 | Y132S-6 | 3 | 15500x12000x6625 |
NZS-15 | Marginal | 15 | 3.5 | 390 | Y132S-4 | 5.5 | 16545x15670x7017 |
NZS-18 | Marginal | 18 | 3.5 | 560 | Y132S-4 | 5.5 | 19742x18864x7047 |
NZS-15 | Marginal | 15 | 3.5 | 390 | Y132S-4 | 5.5 | 17000x15000x7000 |
NZS-18 | Marginal | 18 | 3.5 | 560 | Y132S-4 | 5.5 | 20000x18000x7000 |
