Brief introduction of drum sieve:
This equipment is widely used for screening and classifying mineral materials. Such as metallurgy, mining, chemical, coal, building materials, abrasives, and other industries.
Features of drum sieve(cylinder screen):
1 Include single, double, and muti layer type
2 strong processing ability
3 Easy maintenance
4 High-efficient and power-saving
5 Deputed quality with ISO/CE
Drum Sieve technical parameters
Model | Capacity | Power | Screen Diameter | Screen Length | Discharge Size | Input Size | Dimension | Weig ht |
(t/h) | (kw) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | |
GTS1015 | 50 | 3.0 | 1000 | 1500 | 0~100 | ≤300 | 2600×1400×1700 | 2200 |
GTS1020 | 100 | 4.0 | 1000 | 2000 | 3390×1400×2140 | 2800 | ||
GTS1225 | 160 | 5.5 | 1200 | 2500 | 4146×1600×2680 | 4200 | ||
GTS1530 | 250 | 7.5 | 1500 | 3000 | 4460×1900×2820 | 5100 | ||
GTS1545 | 350 | 11 | 1500 | 4500 | ≤400 | 5960×1900×3080 | 6000 | |
GTS1848 | 450 | 15 | 1800 | 4800 | 6500×2350×4000 | 7500 | ||
GTS2055 | 600 | 22 | 2000 | 5500 | 7500×2550×4800 | 9600 | ||
GTS2265 | 800 | 30 | 2200 | 6500 | 8500×2750×5000 | 12800 |
