Spiral chute



The details of spiral chute

Spiral Chute is made of the fiberglass lined with wear-resistant polyurethane and corundum cover; the advantages are small footprint, without power, moisture proof, anti-rust, wear proof, anti corrosion and no noise, properly suitable for the different feeding particle sizes. it is especially for concentrating sand ore in beach, riverside, seashore and stream.

Features of spiral chute

High recovery ratio, High efficiency beneficiation

Small footprint, Without power

Low operating cost and long working life

Widely use range

Simple installation and easy maintenance

Rust and corrosion resistant;

No noise and no pollution,

The work safe and reliable

Main technical parameters of spiral chute:

Model

5LL-2000

5LL-1500

5LL-1200

5LL-900

5LL-600

Spiral Diameter

(mm)

2000

1500

1200

900

600

Spiral Pitch

(mm)

1200

720/540

720/540

675/540

450/360

Max Spiral Start

3

4

4

4

3

Max turn each start

4

5

5

5

5

Feeding

Particle Size

(mm)

4-0.04

0.8-0.037

0.3-0.03

0.3-0.03

0.2-0.02

Feeding Density

(%)

20-45

25-50

25-55

25-55

25-55

Capacity

(t/h)

15-40

6-8

4-6

2-3

0.8-1.2

Outline

Size

L(mm)

2300

1560

1360

1060

700

W(mm)

2300

1560

1360

1060

700

H(mm)

6500

5230

5230

4000

2600

Weight (kg)

900

800

600

400

150



[Keywords: Spiral chute]
